TM11R-5M2 Series q Subminiature, LAN Modular Jack Connectors
B Recommended PCB mounting patterns
q With Built-in Optical Pipe
11.1
8.89
6.35
3.81
q Without Optical Pipe
8.89
1.27
LED location area
6.35
LED light emission area
3.81
1
Contact No.
1
1.27
No conductive traces
11.4 MAX
8-?1
No conductive traces
11.4 MAX
8- ?1
Contact No.
7 5 3 1
8 6 4 2
8
7
6
5
4
3
2
1
2-?1.6
2- ?2.4
Printed board edge
Connector front edge
11.4
14.75
2
No conductive &
ground traces
11.4 MIN
18.1MIN
2- ?1.6
2-?2.4
Printed board
edge
11.4
14.75
2
No conductive &
ground traces
11.4 MIN
18.1 MIN
Connector
front edge
LED light emitting center
2.7 MAX
4
Suggested LEDs
1.5 MAX
* Recommendations for PCB Design
1 Areas indicated should be free of conductive traces.
2 Area indicated should be free of conductive & ground traces.
3 Recommended board thickness: 1.6mm.
4
To assure that the indicator light pipes operates correctly the LED’s must be installed directly on the PCB, within
recommended dimensions and with light emitting center in upward direction.
Contact applicable manufacturer for LED specification.
B Panel Cutout
q For Both Types, With and Without Built-in Optical Pipe
(33)
Lock lever
3±1 1
15.4
TM21P--88P
1
4.5MIN
PCB mounting surface
2 -0.7
Panel side
* Recommendations for Panel Design
1
Connector front surface
1
0
5.55
3.1MAX
1 The shield contacts should connect with the panel cut-out on all sides.
Note: IPA cleaning at room temperature is recommended for the cleaning of this product.
When an aqueous cleaning agent is to be used, there is a concern that the light pipe (made of polycarbonate
resin) may change color; therefore, please make a selection based on a table showing the effects on the resin.
These tables are issued by the various manufacturers of cleaning agents.
